ยปHCP Packer

packer (configsourcer)

Retrieve the image ID of an image whose metadata is pushed to an HCP Packer registry. The image ID is that of the HCP Packer bucketiteration assigned to the configured channel, with a matching cloud providerand region.

Examples

// The waypoint.hcl file
project = "example-reactjs-project"

variable "image" {
  default = dynamic("packer", {
    bucket          = "nginx"
    channel         = "base"
    region          = "docker"
    cloud_provider  = "docker"
  }
  type = string
  description = "The name of the base image to use for building app Docker images."
}

app "example-reactjs" {
  build {
    use "docker" {
      dockerfile = templatefile("${path.app}"/Dockerfile, {
        base_image = var.image
      }
    }

  deploy {
    use "docker" {}
  }
}


# Multi-stage Dockerfile example
FROM node:19.2-alpine as build
WORKDIR /app
ENV PATH /app/node_modules/.bin:$PATH
COPY package.json ./
COPY package-lock.json ./
RUN npm ci --silent
RUN npm install react-scripts@3.4.1 -g --silent
COPY . ./
RUN npm run build

# ${base_image} below is the Docker repository and tag, templated to the Dockerfile
FROM ${base_image}
COPY nginx/default.conf /etc/nginx/conf.d/
COPY --from=build /app/build /usr/share/nginx/html
EXPOSE 80
CMD ["nginx", "-g", "daemon off;"]

Required Parameters

These parameters are used in dynamic for sourcing configuration values or input variable values.

bucket

The name of the HCP Packer bucket from which to source an image.

  • Type: string

channel

The name of the HCP Packer channel from which to source the latest image.

  • Type: string

cloud

The cloud provider of the machine image to source.

  • Type: string

region

The region set for the machine image's cloud provider.

  • Type: string

Optional Parameters

This plugin has no optional parameters.

Source Parameters

The parameters below are used with waypoint config source-set to configure the behavior this plugin. These are not used in dynamic calls. The parameters used for dynamic are in the previous section.

Required Source Parameters

organization_id

The HCP organization ID.

  • Type: string
project_id

The HCP Project ID.

  • Type: string

Optional Source Parameters

client_id

The OAuth2 Client ID for HCP API operations.

  • Type: string
  • Optional
  • Environment Variable: HCP_CLIENT_ID
client_secret

The OAuth2 Client Secret for HCP API operations.

  • Type: string
  • Optional
  • Environment Variable: HCP_CLIENT_SECRET
