ยปGoogle Cloud Run

For a step by step tutorial on deploying a Waypoint application to Google Cloud Run, visit HashiCorp Learn

Builders

Google Cloud Run uses Docker images for building, which are generated by these builders:

  • Docker
  • Cloud Native Buildpacks

google-cloud-run (platform)

Deploy a container to Google Cloud Run.

Interface

Examples

project = "wpmini"

app "wpmini" {
  labels = {
    "service" = "wpmini",
    "env"     = "dev"
  }

  build {
    use "pack" {}

    registry {
      use "docker" {
        image = "gcr.io/waypoint-project-id/wpmini"
        tag   = "latest"
      }
    }
  }

  deploy {
    use "google-cloud-run" {
      project  = "waypoint-project-id"
      location = "europe-north1"

      port = 5000

      static_environment = {
        "NAME" : "World"
      }

      capacity {
        memory                     = 128
        cpu_count                  = 2
        max_requests_per_container = 10
        request_timeout            = 300
      }

      service_account_name = "cloudrun@waypoint-project-id.iam.gserviceaccount.com"

      auto_scaling {
        max = 10
      }

      cloudsql_instances = ["waypoint-project-id:europe-north1:sql-instance"]

      vpc_access {
        connector = "custom-vpc-connector"
        egress = "all"
      }
    }
  }

  release {
    use "google-cloud-run" {}
  }
}

Required Parameters

These parameters are used in the use stanza for this plugin.

auto_scaling (category)

Configuration to control the auto scaling parameters for Cloud Run.

auto_scaling.max

Maximum number of Cloud Run instances. When the maximum requests per container is exceeded, Cloud Run will create an additional container instance to handle load. This parameter controls the maximum number of instances that can be created.

  • Type: int

capacity (category)

CPU, Memory, and resource limits for each Cloud Run instance.

capacity.cpu_count

Number of CPUs to allocate the Cloud Run instance, min 1, max 2.

  • Type: int
capacity.max_requests_per_container

Maximum number of concurrent requests each instance can handle. When the maximum requests are exceeded, Cloud Run will create an additional instance.

  • Type: int
capacity.memory

Memory to allocate the Cloud Run instance specified in MB, min 128, max 4096.

  • Type: int
capacity.request_timeout

Maximum time a request can take before timing out, max 900.

  • Type: int

location

GCP location, e.g. europe-north-1.

  • Type: string

project

GCP project ID where the Cloud Run instance will be deployed.

  • Type: string

Optional Parameters

These parameters are used in the use stanza for this plugin.

cloudsql_instances

Specify list of CloudSQL instances that the Cloud Run instance will have access to.

  • Type: list of string
  • Optional

port

The port your application listens on.

  • Type: int
  • Optional

service_account_name

Specify a service account email that Cloud Run will use to run the service. You must have the iam.serviceAccounts.actAs permission on the service account.

  • Type: string
  • Optional

static_environment

Additional environment variables to be added to the Cloud Run instance.

  • Type: map of string to string
  • Optional

unauthenticated

Is public unauthenticated access allowed for the Cloud Run instance?.

  • Type: bool
  • Optional

vpc_access (category)

VPCAccess details.

vpc_access.connector

Set VPC Access Connector for the Cloud Run instance.

  • Type: string
  • Optional
vpc_access.egress

Set VPC egress. Supported values are 'all' and 'private-ranges-only'.

  • Type: string
  • Optional

Output Attributes

Output attributes can be used in your waypoint.hcl as variables via artifact or deploy.

id

  • Type: string

region

  • Type: string

resource

  • Type: cloudrun.Deployment_Resource

resource_state

  • Type: opaqueany.Any

revision_id

  • Type: string

url

  • Type: string

google-cloud-run (releasemanager)

Manipulates the Cloud Run APIs to make deployments active.

Interface

Required Parameters

This plugin has no required parameters.

Optional Parameters

This plugin has no optional parameters.
