»Docker

For a step by step tutorial, visit HashiCorp Learn.

docker (builder)

Build a Docker image from a Dockerfile.

If a Docker server is available (either locally or via environment variables such as "DOCKER_HOST"), then "docker build" will be used to build an image from a Dockerfile.

Dockerless Builds

Many hosted environments, such as Kubernetes clusters, don't provide access to a Docker server. In these cases, it is desirable to perform what is called a "dockerless" build: building a Docker image without access to a Docker daemon. Waypoint supports dockerless builds.

Waypoint performs Dockerless builds by leveraging Kaniko within on-demand launched runners. This should work in all supported Waypoint installation environments by default and you should not have to specify any additional configuration.

Interface

Output: docker.Image

Examples

build {
  use "docker" {
    buildkit    = false
    disable_entrypoint = false
  }
}

build {
  use "docker" {
    buildkit    = false
    disable_entrypoint = false
  }
}

Required Parameters

This plugin has no required parameters.

Optional Parameters

These parameters are used in the use stanza for this plugin.

auth (category)

The authentication information to log into the docker repository.

auth.auth

Type: string
Optional

auth.email

Type: string
Optional

auth.hostname

Hostname of Docker registry.

Type: string
Optional

auth.identityToken

Token used to authenticate user.

Type: string
Optional

auth.password

Password of Docker registry account.

Type: string
Optional

auth.registryToken

Bearer tokens to be sent to Docker registry.

Type: string
Optional

auth.serverAddress

Address of Docker registry.

Type: string
Optional

auth.username

Username of Docker registry account.

Type: string
Optional

build_args

Build args to pass to docker for the build step.

An array of strings of build-time variables passed as build-arg to docker for the build step.

Type: map of string to string
Optional

buildkit

If set, use the buildkit builder from Docker.

Type: bool
Optional

context

Build context path.

Type: string
Optional

disable_entrypoint

If set, the entrypoint binary won't be injected into the image.

The entrypoint binary is what provides extended functionality such as logs and exec. If it is not injected at build time the expectation is that the image already contains it.

Type: bool
Optional

dockerfile

The path to the Dockerfile.

Set this when the Dockerfile is not APP-PATH/Dockerfile.

Type: string
Optional

no_cache

Do not use cache when building the image.

Ensures a clean image build.

Type: bool
Optional

platform

Set target platform to build container if server is multi-platform capable.

Must enable Docker buildkit to use the 'platform' flag.

Type: string
Optional

target

The target build stage in a multi-stage Dockerfile.

If buildkit is enabled unused stages will be skipped.

Type: string
Optional

Output Attributes

Output attributes can be used in your waypoint.hcl as variables via artifact or deploy.

architecture

Type: string


Type: string

location

Type: docker.isImage_Location

docker-pull (builder)

Use an existing, pre-built Docker image.

This builder will automatically inject the Waypoint entrypoint. You can disable this with the "disable_entrypoint" configuration.

If you wish to rename or retag an image, use this along with the "docker" registry option which will rename/retag the image and then push it to the specified registry.

If Docker isn't available (the Docker daemon isn't running or a DOCKER_HOST isn't set), a daemonless solution will be used instead.

If "disable_entrypoint" is set to true and the Waypoint configuration has no registry, this builder will not physically pull the image. This enables Waypoint to work in environments where the image is built outside of Waypoint (such as in a CI pipeline).

Interface

Input: component.Source
Output: docker.Image

Examples

build {
  use "docker-pull" {
    image = "gcr.io/my-project/my-image"
    tag   = "abcd1234"
  }
}

build {
  use "docker-pull" {
    image = "gcr.io/my-project/my-image"
    tag   = "abcd1234"
  }
}

Required Parameters

These parameters are used in the use stanza for this plugin.


The image to pull.

This should NOT include the tag (the value following the ':' in a Docker image). Use tag to define the image tag.

Type: string

Optional Parameters

These parameters are used in the use stanza for this plugin.

auth (category)

The authentication information to log into the docker repository.

auth.auth

Type: string
Optional

auth.email

Type: string
Optional

auth.hostname

Hostname of Docker registry.

Type: string
Optional

auth.identityToken

Token used to authenticate user.

Type: string
Optional

auth.password

Password of Docker registry account.

Type: string
Optional

auth.registryToken

Bearer tokens to be sent to Docker registry.

Type: string
Optional

auth.serverAddress

Address of Docker registry.

Type: string
Optional

auth.username

Username of Docker registry account.

Type: string
Optional

disable_entrypoint

If set, the entrypoint binary won't be injected into the image.

The entrypoint binary is what provides extended functionality such as logs and exec. If it is not injected at build time the expectation is that the image already contains it.

Type: bool
Optional

encoded_auth

The authentication information to log into the docker repository.

WARNING: be very careful to not leak the authentication information by hardcoding it here. Use a helper function like file() to read the information from a file not stored in VCS.

Type: string
Optional

Output Attributes

Output attributes can be used in your waypoint.hcl as variables via artifact or deploy.

architecture

Type: string


Type: string

location

Type: docker.isImage_Location

docker-ref (builder)

Use an existing, pre-built Docker image without modifying it.

Interface

Input: component.Source
Output: docker.Image

Examples

build {
  use "docker-ref" {
    image = "gcr.io/my-project/my-image"
    tag   = "abcd1234"
  }
}

build {
  use "docker-ref" {
    image = "gcr.io/my-project/my-image"
    tag   = "abcd1234"
  }
}

Required Parameters

These parameters are used in the use stanza for this plugin.


The image to pull.

This should NOT include the tag (the value following the ':' in a Docker image). Use tag to define the image tag.

Type: string

Optional Parameters

This plugin has no optional parameters.

Output Attributes

Output attributes can be used in your waypoint.hcl as variables via artifact or deploy.

architecture

Type: string


Type: string

location

Type: docker.isImage_Location

docker (registry)

Push a Docker image to a Docker compatible registry.

Interface

Input: docker.Image
Output: docker.Image

Examples

build {
  use "docker" {}
  registry {
    use "docker" {
      image = "hashicorp/http-echo"
      tag   = "latest"
    }
  }
}

build {
  use "docker" {}
  registry {
    use "docker" {
      image = "hashicorp/http-echo"
      tag   = "latest"
    }
  }
}

Required Parameters

These parameters are used in the use stanza for this plugin.


The image to push the local image to, fully qualified.

This value must be the fully qualified name to the image. for example: gcr.io/waypoint-demo/demo.

Type: string

Optional Parameters

These parameters are used in the use stanza for this plugin.

auth (category)

The authentication information to log into the docker repository.

auth.auth

Type: string
Optional

auth.email

Type: string
Optional

auth.hostname

Hostname of Docker registry.

Type: string
Optional

auth.identityToken

Token used to authenticate user.

Type: string
Optional

auth.password

Password of Docker registry account.

Type: string
Optional

auth.registryToken

Bearer tokens to be sent to Docker registry.

Type: string
Optional

auth.serverAddress

Address of Docker registry.

Type: string
Optional

auth.username

Username of Docker registry account.

Type: string
Optional

encoded_auth

The authentication information to log into the docker repository.

The format of this is base64-encoded JSON. The structure is the AuthConfig structure used by Docker. WARNING: be very careful to not leak the authentication information by hardcoding it here. Use a helper function like file() to read the information from a file not stored in VCS.

Type: string
Optional

insecure

Access the registry via http rather than https.

This indicates that the registry should be accessed via http rather than https. Not recommended for production usage.

Type: bool
Optional

local

If set, the image will only be tagged locally and not pushed to a remote repository.

Type: bool
Optional

password

Password associated with username on the registry.

This optional conflicts with encoded_auth and thusly only one can be used at a time. If both are used, encoded_auth takes precedence.

Type: string
Optional

username

Username to authenticate with the registry.

This optional conflicts with encoded_auth and thusly only one can be used at a time. If both are used, encoded_auth takes precedence.

Type: string
Optional

Output Attributes

Output attributes can be used in your waypoint.hcl as variables via artifact or deploy.

architecture

Type: string


Type: string

location

Type: docker.isImage_Location

docker (platform)

Deploy a container to Docker, local or remote.

Interface

Input: docker.Image
Output: docker.Deployment

Examples

deploy {
  use "docker" {
    command      = ["ps"]
    service_port = 3000
    static_environment = {
      "environment": "production",
      "LOG_LEVEL": "debug"
    }
  }
}

deploy {
  use "docker" {
    command      = ["ps"]
    service_port = 3000
    static_environment = {
      "environment": "production",
      "LOG_LEVEL": "debug"
    }
  }
}

Required Parameters

These parameters are used in the use stanza for this plugin.

client_config

Client config for remote Docker engine.

This config block can be used to configure a remote Docker engine. By default Waypoint will attempt to discover this configuration using the environment variables: DOCKER_HOST to set the url to the docker server. DOCKER_API_VERSION to set the version of the API to reach, leave empty for latest. DOCKER_CERT_PATH to load the TLS certificates from. DOCKER_TLS_VERIFY to enable or disable TLS verification, off by default.

Type: docker.ClientConfig

Optional Parameters

These parameters are used in the use stanza for this plugin.

auth (category)

The authentication information to log into the docker repository.

auth.auth

Type: string
Optional

auth.email

Type: string
Optional

auth.hostname

Hostname of Docker registry.

Type: string
Optional

auth.identityToken

Token used to authenticate user.

Type: string
Optional

auth.password

Password of Docker registry account.

Type: string
Optional

auth.registryToken

Bearer tokens to be sent to Docker registry.

Type: string
Optional

auth.serverAddress

Address of Docker registry.

Type: string
Optional

auth.username

Username of Docker registry account.

Type: string
Optional

binds

A 'source:destination' list of folders to mount onto the container from the host.

A list of folders to mount onto the container from the host. The expected format for each string entry in the list is source:destination. So for example: `binds: ["host_folder/scripts:/scripts"].

Type: list of string
Optional

command

The command to run to start the application in the container.

Type: list of string
Optional
Default: the image entrypoint

extra_ports

Additional TCP ports the application is listening on to expose on the container.

Used to define and expose multiple ports that the application is listening on for the container in use. These ports will get merged with service_port when creating the container if defined.

Type: list of uint
Optional

force_pull

Always pull the docker container from the registry.

Type: bool
Optional
Default: false

labels

A map of key/value pairs to label the docker container with.

A map of key/value pair(s), stored in docker as a string. Each key/value pair must be unique. Validiation occurs at the docker layer, not in Waypoint. Label keys are alphanumeric strings which may contain periods (.) and hyphens (-).

Type: map of string to string
Optional

networks

An list of strings with network names to connect the container to.

A list of networks to connect the container to. By default the container will always connect to the waypoint network.

Type: list of string
Optional
Default: waypoint

resources

A map of resources to configure the container with, such as memory or cpu limits.

These options are used to configure the container used when deploying with docker. Currently, the supported resources are 'memory' and 'cpu' limits. The field 'memory' is expected to be defined as "512MB", "44kB", etc.

Type: map of string to string
Optional

scratch_path

A path within the container to store temporary data.

Docker will mount a tmpfs at this path.

Type: string
Optional

service_port

Port that your service is running on in the container.

Type: uint
Optional
Default: 3000

static_environment

Environment variables to expose to the application.

These environment variables should not be run of the mill configuration variables, use waypoint config for that. These variables are used to control over all container modes, such as configuring it to start a web app vs a background worker.

Type: map of string to string
Optional

Output Attributes

Output attributes can be used in your waypoint.hcl as variables via artifact or deploy.

container

Type: string

id

Type: string

name

Type: string

resource_state

Type: opaqueany.Any

docker (task)

Launch a Docker container as a task.

If a Docker server is available (either locally or via environment variables such as "DOCKER_HOST"), then it will be used to start the container.

Interface

Examples

task {
  use "docker" {
        force_pull = true
  }
}

task {
  use "docker" {
        force_pull = true
  }
}

Required Parameters

These parameters are used in the use stanza for this plugin.

client_config

Type: docker.ClientConfig

Optional Parameters

These parameters are used in the use stanza for this plugin.

binds

A 'source:destination' list of folders to mount onto the container from the host.

A list of folders to mount onto the container from the host. The expected format for each string entry in the list is source:destination. So for example: binds: ["host_folder/scripts:/scripts"].

Type: list of string
Optional

debug_containers

Type: bool
Optional

force_pull

Type: bool
Optional

labels

A map of key/value pairs to label the docker container with.

Type: map of string to string
Optional

networks

A list of strings with network names to connect the container to.

A list of networks to connect the container to. By default the container will always connect to the waypoint network.

Type: list of string
Optional
Default: waypoint

resources (category)

The resources that the tasks should use.

resources.cpu

The cpu shares that the tasks should use.

Type: int64
Optional

resources.memory

The amount of memory to use. Defined as '512MB', '44kB', etc.

Type: string
Optional

static_environment

Environment variables to expose to the application.

These variables are used to control all of a container's modes, such as configuring it to start a web app vs a background worker. These environment variables should not be common configuration variables normally set in waypoint config.

Type: map of string to string
Optional

Output Attributes

Output attributes can be used in your waypoint.hcl as variables via artifact or deploy.

id

Type: string
